The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3-inch 128x64 Graphic LCD Display Module | SPI Interface | White Background with Gray Text | FSTN Positive | Transflective Polarizer HTM12864-123-31W-A3P | Graphic LCD Module | 128x64 |
|
71.0x62.0x7.8 | 65.5x38.0 | 60.77x32.93 | 6H | white | 12PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7567 | ||
| 3.0 inch yellow-green 128x64 dot matrix graphic LCD display module | SPI interface | STN+ | ST7567 HTM12864-123-01Y-A3P | Graphic LCD Module | 128x64 |
|
71.0x62.0x7.8 | 65.5x38.0 | 60.77x32.93 | 6H | YG | 12PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7567 | ||
| 3-inch 128x64 Graphic LCD Display | FSTN Positive Display | Red, Green and Blue Backlight | Fully Transmissive Polarizer HTM12864H-35S-A5P | Graphic LCD Module | 128x64 |
|
63.0x52.2x11.5 | 54.0x36.0 | 49.88x31.32 | 0.38x0.34 | 6H | R/G/B | FFC-20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | SBN0064G | |
| 3-inch 128x64 graphic LCD display | STN positive display | yellow-green backlight | MCU |Arduino | SBN0064G HTM12864H-11Y-A5P | Graphic LCD Module | 128x64 |
|
63.0x52.2x11.5 | 54.0x36.0 | 49.88x31.32 | 0.38x0.34 | 6H | YG | FFC-20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | SBN0064G | |
| 3 inch 128x64 LCD Graphic Display Module | DFSTN Negative Display | White on Black | Transflective Polarizer HTM12864H-41W-A5P | Graphic LCD Module | 128x64 |
|
63.0x52.2x11.5 | 54.0x36.0 | 49.88x31.32 | 0.38x0.34 | 6H | white | FFC-20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | SBN0064G | |
| 3 inch 128x64 LCD Graphic Display Module |STN Negative Display | White Backlight | White on Blue HTM12864H-25W-A5P | Graphic LCD Module | 128x64 |
|
63.0x52.2x11.5 | 54.0x36.0 | 49.88x31.32 | 0.38x0.34 | 6H | white | FFC-20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | SBN0064G | |
| 3"128x64 LCD Graphic Display/128x64 Graphic LCD Module/FSTN Positive White Backlight /Transflective Polarizer HTM12864H-31W-A5P | Graphic LCD Module | 128x64 |
|
63.0x52.2x11.5 | 54.0x36.0 | 49.88x31.32 | 0.38x0.34 | 6H | white | FFC-20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | SBN0064G | |
| 3" 128 x 64 LCD Graphic Display | 128x64 Graphic LCD Module | STN Positive Display Yellow-Green Backlight HTM12864H-01Y-A5P | Graphic LCD Module | 128x64 |
|
63.0x52.2x11.5 | 54.0x36.0 | 49.88x31.32 | 0.38x0.34 | 6H | YG | FFC-20PIN | MCU | 6H | -20~70℃ | 5.0V | SBN0064G | |
| 2.7 inch 128x64 LCD Graphic Liquid Crystal Dot Matrix Module | Red Green Blue Backlight | FSTN Positive Polarizer | Arduino HTM12864K-35S-A5P | Graphic LCD Module | 128x64 |
|
75X52.7X8.5 | 60X32.6 | 55.01X27.49 | 0.43x0.43 | 6H | R/G/B | FFC-20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | SBN0064G | |
| 2.7 inch 128x64 LCD Graphic Liquid Crystal Dot Matrix Module | | STN Positive Polarizer | Yellow-Green Backlight HTM12864K-11Y-A5P | Graphic LCD Module | 128x64 |
|
75X52.7X8.5 | 60X32.6 | 55.01X27.49 | 0.43x0.43 | 6H | YG | FFC-20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | SBN0064G |
