The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3.0" LCD 128x64 Graphic LCD Display | STN Positive Display | Yellow-Green Backlight | ST7565R HTM12864-85-01Y-A3P | Graphic LCD Module | 128x64 |
|
71.0x62.0x7.8 | 65.5x38.0 | 60.77x32.93 | 0.515x0.475 | 6H | YG | 12PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.2 inch 128x64 Graphic LCD | 128 x 64 Graphic LCD Display Module | SPI Interface | 3.3V | RGB+RGB Backlight arduino HTM12864-108-35S-A3P | Graphic LCD Module | 128x64 |
|
93.0x70.0x7.1 | 72.0x39.5 | 66.52x33.24 | 0.52x0.52 | 6H | R/G/B | 20PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.2 Inch 128x64 Yellow-Green Background Graphic LCD LCD Display Module | Graphic LCD Display Module HTM12864-108-11Y-A3P | Graphic LCD Module | 128x64 |
|
93.0x70.0x7.1 | 72.0x39.5 | 66.52x33.24 | 0.52x0.52 | 6H | YG | 20PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.2 inch 128x64 Graphic LCD Display Module | 128x64 Graphic LCD Display Module | Blue on Gray Background HTM12864-108-11W-A3P | Graphic LCD Module | 128x64 |
|
93.0x70.0x7.1 | 72.0x39.5 | 66.52x33.24 | 0.52x0.52 | 6H | white | 20PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.2 Inch 128x64 Black Graphic Liquid Crystal LCD Display Module | White Text on Black Background | SPI Interface | 3.3V HTM12864-108-41W-A3P | Graphic LCD Module | 128x64 |
|
93.0x70.0x13.5 | 72.0x39.5 | 66.52x33.24 | 0.52x0.52 | 6H | white | 20PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.2 inch 128x64 Graphic LCD Display Module | Gray Text on White Background | SPI Interface | For Arduino | 3.3V | White Backlight HTM12864-108-31W-A3P | Graphic LCD Module | 128x64 |
|
93.0x70.0x7.1 | 72.0x39.5 | 66.52x33.24 | 0.52x0.52 | 6H | white | 20PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.2" Yellow-Green 128x64 Graphic LCD Display Module | SPI Interface | For Arduino | 3.3V HTM12864-108-01Y-A3P | Graphic LCD Module | 128x64 |
|
93.0x70.0x7.1 | 72.0x39.5 | 66.52x33.24 | 0.52 | 6H | YG | 20PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.0 inch 128x64 Graphic LCD Module | RGB Backlight | SPI Interface | Arduino HTM12864-109-35S-A3P | Graphic LCD Module | 128x64 |
|
93.0x70.0x13.5 | 65.5x38.0 | 60.77x32.93 | 0.51x0.48 | 6H | R/G/B | 20PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.0 inch 128x64 Graphic LCD Module | STN+Yellow-Green Backlight | For Arduino | SPI Interface | 3.3V HTM12864-109-11Y-A3P | Graphic LCD Module | 128x64 |
|
93.0x70.0x13.5 | 65.5x38.0 | 60.77x32.93 | 0.51x0.48 | 6H | YG | 20PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.0 inch 128x64 Graphic LCD Module | STN+White Backlight | Gray Background Blue Graphic LCD HTM12864-109-11W-A3P | Graphic LCD Module | 128x64 |
|
93.0x70.0x13.5 | 65.5x38.0 | 60.77x32.93 | 0.51x0.48 | 6H | white | 20PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R |
