The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5.1" 128 x 64 Graphic LCD Module | STN | MCU | Blue on Gray | S6B0108 | 5.0V arduino HTM12864-30-11W-A5P | Graphic LCD Module | 128x64 |
|
144.0x98.0x9.1 | 114.0x64.0 | 107.44x57.51 | 0.90x0.84 | 6H | white | 18PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | S6B0108 | |
| 5.1 inch 128x64 LCD Graphic Module | DFSTN Negative Display | MCU | White on Black | S6B0108 | 5.0V HTM12864-30-41W-A5P | Graphic LCD Module | 128x64 |
|
144.0x98.0x9.1 | 114.0x64.0 | 107.44x57.51 | 0.90x0.84 | 6H | white | 18PIN | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3V | S6B0108 | |
| 5.1" 128x64 Graphic LCD Module | FSTN Positive Display | MCU | Grey Text on White Background | S6B0108 | 5.0V arduino HTM12864-30-31W-A5P | Graphic LCD Module | 128x64 |
|
144.0x98.0x9.1 | 114.0x64.0 | 107.44x57.51 | 0.90x0.84 | 6H | white | 18PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 5.0V | S6B0108 | |
| 5.1" 128x64 LCD Graphic LCD Module | STN Positive Display | MCU | Yellow-Green Backlight | S6B0108 arduino HTM12864-30-01Y-A5P | Graphic LCD Module | 128x64 |
|
144.0x98.0x9.1 | 114.0x64.0 | 107.44x57.51 | 0.90x0.84 | 6H | YG | 18PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | S6B0108 | |
| 3.0 inch 128x64 Graphic LCD Module | ST7565R | SPI | RGB Red Backlight | FSTN Positive Display HTM12864-85-35S-A3P | Graphic LCD Module | 128x64 |
|
71.0x62.0x7.8 | 65.5x38.8 | 60.77x32.93 | 0.515x0.475 | 6H | R/G/B | 12PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.0 inch 128x64 Graphic LCD Display Module | ST7565R | SPI | Yellow-Green Backlight | STN Positive Display arduino HTM12864-85-11Y-A3P | Graphic LCD Module | 128x64 |
|
71.0x62.0x7.8 | 65.5x38.8 | 60.77x32.93 | 0.515x0.475 | 6H | YG | 12PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.0" 128x64 Graphic LCD Display Module | ST7565R | SPI | STN Positive Display HTM12864-85-11W-A3P | Graphic LCD Module | 128x64 |
|
71.0x62.0x7.8 | 65.5x38.8 | 60.77x32.93 | 0.515x0.475 | 6H | white | 12PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.0 inch LCD 128x64 Blue Graphic LCD Display | STN Negative Display | White Backlight | ST7565R | SPI arduino HTM12864-85-41W-A3P | Graphic LCD Module | 128x64 |
|
71.0x62.0x7.8 | 65.5x38.8 | 60.77x32.93 | 0.515x0.475 | 6H | white | 12PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.0 inch LCD 128x64 Blue Graphic LCD Display | STN Negative Display | White Backlight | ST7565R | SPI arduino HTM12864-85-25W-A3P | Graphic LCD Module | 128x64 |
|
71.0x62.0x7.8 | 65.5x38.8 | 60.77x32.93 | 0.515x0.475 | 6H | white | 12PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.0" LCD 128x64 Graphic LCD Display | FSTN Positive Display | White Backlight | ST7565R | SPI arduino HTM12864-85-31W-A3P | Graphic LCD Module | 128x64 |
|
71.0x62.0x7.8 | 65.5x38.8 | 60.77x32.93 | 0.515x0.475 | 6H | white | 12PIN | SPI | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R |
